Honda CB750F2 Seven Fifty
Manufacturer
Also called CB 750 F2 Seven Fifty
Production 1992 - 2002
ClassNaked
Engine
air-cooled, four-stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Bore / Stroke66.0mm x 66.0mm
Compression ratio9.3:1
Horsepower72.95 HP (54.4 KW) @ 8500RPM
Torque45.73 ft/lbs (62.0 Nm) @ 7500RPM
Fuel System4x34mm carburetors
TransmissionGear box: 5-speed, manual
Final Drive: chain
SuspensionFront: 41mm telescopic fork
Rear: dual adjustable shock absorbers
BrakesFront: dual 296mm discs, 2-piston calipers
Rear: single 240mm disc, 1-piston caliper
Front Tire120/70 - ZR17
Rear Tire150/70 - ZR17
Weight 215.0 kg (wet)
Recommended OilHonda GN4 10W-40
Manuals Service Manual


The Honda CB 750 F2 Seven Fifty was a air-cooled, four-stroke, transverse four cylinder, DOHC, 4 valves per cylinder Naked motorcycle produced by Honda between 1992 and 2002. Max torque was 45.73 ft/lbs (62.0 Nm) @ 7500 RPM. Claimed horsepower was 72.95 HP (54.4 KW) @ 8500 RPM.

Engine[edit]

A 66.0mm bore x 66.0mm stroke result in a displacement of just 747.0 cubic centimeters.

Cb 750 Seven Fifty Manual Free

Drive[edit]

The bike has a 5-speed, manual transmission.

Chassis[edit]

It came with a 120/70 - ZR17 front tire and a 150/70 - ZR17 rear tire. Stopping was achieved via dual 296mm discs, 2-piston calipers in the front and a single 240mm disc, 1-piston caliper in the rear. The front suspension was a 41mm telescopic fork while the rear was equipped with a dual adjustable shock absorbers.

1992 Honda CB 750 F2 Seven Fifty[edit]

The 1992 MY Honda CB 750 F2 Seven Fifty has, at its heart, an air-cooled, four-stroke, 747cc, transverse four cylinder powerplant that was mated to a five-speed manual transmission with a chain final drive, and can reach a maximum power output of 73 horsepower and 62 Nm of torque.

In addition, it comes with gold, cast-aluminum wheels, a chromed, dual-sided exhaust system, a dual seat with a pillion grab handle, wide handlebars, analogue instrumentation dials, a telescopic front fork coupled to dual shock absorbers in the rear, dual front disc brakes, a round headlight and a blacked-out, steel frame.

SOHC/4


1993 Honda CB 750 F2 Seven Fifty[edit]

The 1993 MY Honda CB 750 F2 Seven Fifty has standard features such as gold, cast-aluminum wheels, a chromed, dual-sided exhaust system, a dual seat with a pillion grab handle, wide handlebars, analogue instrumentation dials, a telescopic front fork coupled to dual shock absorbers in the rear, dual front disc brakes, a round headlight and a blacked-out, steel frame.

In the engine department it is powered by a four-stroke, air-cooled, 747cc, transverse four cylinder powerhouse, paired to a five-speed manual transmission with a chain final drive, that can produce a claimed 73 horsepower and 62 Nm of torque.


1994 Honda CB 750 F2 Seven Fifty[edit]

The 1994 MY Honda CB 750 F2 Seven Fifty boasts a maximum power output of 73 horsepower and 62 Nm of torque from its air-cooled, four-stroke, 747cc, transverse four cylinder powerplant that was mated to a five-speed manual transmission with a chain final drive.

In addition it comes equipped with gold, cast-aluminum wheels, a chromed, dual-sided exhaust system, a dual seat with a pillion grab handle, wide handlebars, analogue instrumentation dials, a telescopic front fork coupled to dual shock absorbers in the rear, dual front disc brakes, a round headlight and a blacked-out, steel frame.


1995 Honda CB 750 F2 Seven Fifty[edit]

The 1995 MY Honda CB 750 F2 Seven Fifty has standard features such as with gold, cast-aluminum wheels, a chromed, dual-sided exhaust system, a dual seat with a pillion grab handle, wide handlebars, analogue instrumentation dials, a telescopic front fork coupled to dual shock absorbers in the rear, dual front disc brakes, a round headlight and a blacked-out, steel frame.

Also, it can produce a claimed 73 horsepower and 62 Nm of torque from its four-stroke, air-cooled, 747cc, transverse four cylinder powerplant that was mated to a five-speed manual transmission with a chain final drive.


1996 Honda CB 750 F2 Seven Fifty[edit]

The 1996 MY Honda CB 750 F2 Seven Fifty has, at its heart, an air-cooled, four-stroke, 747cc, transverse four cylinder powerhouse that was paired to a five-speed manual transmission with a chain final drive, and can reach a maximum power output of 73 horsepower and 62 Nm of torque.

The Japanese engineers have also fitted it with a dual seat with a passenger grab handle, die-cast aluminum wheels, a round headlight, wide handlebars, a blacked-out, steel frame, a chromed exhaust system, a 41mm telescopic front fork, dual adjustable shock absorbers as a rear suspension and an analogue instrument cluster.


1997 Honda CB 750 F2 Seven Fifty[edit]

Manual

The 1997 MY Honda CB 750 F2 Seven Fifty comes with fittings such as a dual seat with a passenger grab handle, die-cast aluminum wheels, a round headlight, wide handlebars, a blacked-out, steel frame, a chromed exhaust system, a 41mm telescopic front fork, dual adjustable shock absorbers as a rear suspension and an analogue instrument cluster.

In the engine department it is powered by a four-stroke, air-cooled, 747cc, transverse four cylinder powerplant, mated to a five-speed manual transmission with a chain final drive, that can produce a claimed 73 horsepower and 62 Nm of torque.

Vintage CB750 - Honda CB750 Motorcycle Parts


1998 Honda CB 750 F2 Seven Fifty[edit]

The 1998 MY Honda CB 750 F2 Seven Fifty boasts a maximum power output of 73 horsepower and 62 Nm of torque from its air-cooled, four-stroke, 747cc, transverse four cylinder powerplant that was paired to a five-speed manual transmission with a chain final drive.

Also, it has standard features such as a dual seat with a passenger grab handle, die-cast aluminum wheels, a round headlight, wide handlebars, a blacked-out, steel frame, a chromed exhaust system, a 41mm telescopic front fork, dual adjustable shock absorbers as a rear suspension and an analogue instrument cluster.

750


1999 Honda CB 750 F2 Seven Fifty[edit]

The 1999 MY Honda CB 750 F2 Seven Fifty has been equipped with a dual seat with a passenger grab handle, die-cast aluminum wheels, a round headlight, wide handlebars, a blacked-out, steel frame, a chromed exhaust system, a 41mm telescopic front fork, dual adjustable shock absorbers as a rear suspension and an analogue instrument cluster.

In addition, it can produce a claimed 73 horsepower and 62 Nm of torque from its four-stroke, air-cooled, 747cc, transverse four cylinder powerhouse that was mated to a five-speed manual transmission with a chain final drive.

Cached


2000 Honda CB 750 F2 Seven Fifty[edit]

The 2000 MY Honda CB 750 F2 Seven Fifty has, at its heart, a four-stroke, air-cooled, 747cc, transverse four cylinder powerplant that was paired to a five-speed manual transmission with a chain final drive, and can reach a maximum power output of 73 horsepower and 62 Nm of torque.

CB750

Also, it has features such as a 41mm adjustable telescopic fork, adjustable shock absorbers as a rear suspension, dual front disc brakes coupled to a rear disc brake, a blacked-out, steel frame, a chromed, exhaust system, blacked-out, cast-aluminum wheels, wide handlebars, a dual seat with a pillion grab handle and an analogue instrumentation panel.


2001 Honda CB 750 F2 Seven Fifty[edit]

The 2001 MY Honda CB 750 F2 Seven Fifty has been fitted by the Japanese engineers with a 41mm adjustable telescopic fork, adjustable shock absorbers as a rear suspension, dual front disc brakes coupled to a rear disc brake, a blacked-out, steel frame, a chromed, exhaust system, blacked-out, cast-aluminum wheels, wide handlebars, a dual seat with a pillion grab handle and an analogue instrumentation panel.

In the engine department it is powered by an air-cooled, four-stroke, 747cc, transverse four cylinder powerhouse, mated to a five-speed manual transmission with a chain final drive, that can produce a claimed 73 horsepower and 62 Nm of torque.


2002 Honda CB 750 F2 Seven Fifty[edit]

The 2002 MY Honda CB 750 F2 Seven Fifty boasts a maximum power output of 73 horsepower and 62 Nm of torque from its four-stroke, air-cooled, 747cc, transverse four cylinder powerplant that was mated to a five-speed manual transmission with a chain final drive.

In addition, it come s equipped with a 41mm adjustable telescopic fork, adjustable shock absorbers as a rear suspension, dual front disc brakes coupled to a rear disc brake, a blacked-out, steel frame, a chromed, exhaust system, blacked-out, cast-aluminum wheels, wide handlebars, a dual seat with a pillion grab handle and an analogue instrumentation panel.


In Media[edit]

Retrieved from 'https://www.cyclechaos.com/w/index.php?title=Honda_CB750F2_Seven_Fifty&oldid=194876'
From BikesWiki.com, Japanese Motorcycle Encyclopedia
Jump to: navigation, search

Class: standard

Production: 1991-2003, 2005-2008

Also called: Honda CB750F2, Honda CB750 Nighthawk

Models
Honda CB750 Nighthawk

1991-2003

(North America)

Honda CB750 F2 Seven Fifty

1992-2001

(Europe, Japan)

Honda CB750 F2 Seven Fifty

2004-2008

(Japan)

Honda CB750 Nighthawk
Honda CB750 F2 Seven Fifty
Honda CB750 F2 Seven Fifty

History

History
YearCountryName / Frame / Engine
1991North AmericaName: Honda CB750 Nighthawk

Frame: JH2RC381MMXXXXXX

1992North America, Europe, JapanName: Honda CB750 Nighthawk, Honda CB750 F2 Seven Fifty

Frame: JH2RC381NMXXXXXX (North America), RC42XXXXXXX (Europe), RC42-100XXXX (Japan)

Code: CB750F2N (Europe)

1993North America, JapanName: Honda CB750 Nighthawk, Honda CB750 F2 Seven Fifty

Frame: JH2RC381PMXXXXXX (North America), RC42-100XXXX (Japan)

1994Europe, JapanName: Honda CB750 F2 Seven Fifty

Frame: RC42XXXXXXX (Europe), RC42-100XXXX (Japan)

Code: CB750F2R (Europe)

1995North America, Europe, JapanName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC381SMXXXXXX (North America), RC42-110XXXX (Japan), RC42XXXXXXX (Europe)

Code: CB750F2S (Europe)

1996North America, EuropeName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC381TMXXXXXX (North America), RC42XXXXXXX (Europe)

Code: CB750F2T (Europe)

1997North America, EuropeName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC381VMXXXXXX (North America), RC42XXXXXXX (Europe)

Code: CB750F2V (Europe)

1998North America, EuropeName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC381WMXXXXXX (North America), RC42XXXXXXX (Europe)

Code: CB750F2W (Europe)

1999North America, EuropeName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC381XMXXXXXX (North America), RC42XXXXXXX (Europe)

Code: CB750F2X (Europe)

2000North AmericaName: Honda CB750 Nighthawk

Frame: JH2RC381YMXXXXXX (North America)

2001North America, Europe, JapanName: Honda CB750 F2 Seven Fifty, Honda CB750 Nighthawk

Frame: JH2RC3811MXXXXXX (North America), RC42XXXXXXX (Europe), RC42-125XXXX (Japan)

Code: CB750F21 (Europe), CB750FII1 (Japan)

2002North AmericaName: Honda CB750 Nighthawk

Frame: JH2RC3812MXXXXXX (North America)

2003North AmericaName: Honda CB750 Nighthawk

Frame: JH2RC3813MXXXXXX (North America)

2004JapanName: Honda CB750 F2 Seven Fifty

Frame: RC42-135XXXX

Code: CB750FII4

2006JapanName: Honda CB750 F2 Seven Fifty

Frame: RC42-160XXXX

Code: CB750FII6

2007JapanName: Honda CB750 F2 Seven Fifty, Special Edition

Frame: RC42-170XXXX

Code: CB750FII7

2008JapanName: Honda CB750 F2 Seven Fifty

Frame: RC42-171XXXX

Code: CB750FII8

Specifications

Honda CB750 (F2 Seven Fifty, Nighthawk): specs.

Specifications
DIMENSIONSOverall length2220 mm / 87,4 in – CB750 F2 Seven Fifty

2185 mm / 86,0 in – CB750 Nighthawk

Overall width780 mm / 30,7 in – CB750 F2 Seven Fifty

800 mm / 31,5 in – CB750 Nighthawk

Overall height1100 mm / 43,3 in – CB750 F2 Seven Fifty

1135 mm / 44,7 in – CB750 Nighthawk

Seat height795 mm / 31,3 in – CB750 F2 Seven Fifty

780 mm / 30,7 in – CB750 Nighthawk

Wheelbase1495 mm / 58,9 in – CB750 F2 Seven Fifty

1505 mm / 59,3 in – CB750 Nighthawk

Ground clearance130 mm / 5,1 in – CB750 F2 Seven Fifty

140 mm / 5,5 in – CB750 Nighthawk

Dry weight215 kg / 474 lbs – CB750 F2 Seven Fifty

210 kg / 463 lbs (212 kg / 467 lbs - California) – CB750 Nighthawk

Curb (wet) weight235 kg / 518 lbs – CB750 F2 Seven Fifty

226 kg / 498 lbs (228 kg / 503 lbs - California) – CB750 Nighthawk

FRAMETypeDouble cradle (steel)
Front suspension, travelTelescopic fork 41 mm, 130 mm / 5,1 in – CB750 F2 Seven Fifty

Telescopic fork 41 mm, 140 mm / 5,5 in – CB750 Nighthawk

Rear suspension, travelSwingarm with twin-shock (+ reserve-tank), 110 mm / 4,3 in – CB750 F2 Seven Fifty

Adjustment: spring pre-load

Swingarm with twin-shock, 110 mm / 4,3 in - CB750 Nighthawk

Adjustment: spring pre-load

Front tire size120/70-17 58V – CB750 F2 Seven Fifty

110/80-18 58H – CB750 Nighthawk

Rear tire size150/70-17 69V – CB750 F2 Seven Fifty

140/70-17 66V – CB750 Nighthawk

Front brakeDouble disc, 296 mm, 2-piston calipers – CB750 F2 Seven Fifty

Single disc, 296 mm, 2-piston calipers - CB750 Nighthawk

Rear brakeSingle disc, 240 mm, 1-piston caliper – CB750 F2 Seven Fifty

Drum - CB750 Nighthawk

Fuel capacity20,0 l / 5,3 US gal (reserve – 3l) – CB750 F2 Seven Fifty

18,0 l / 4,76 US gal (reserve – 3l) - CB750 Nighthawk

Trail91 mm / 3,6 in – CB750 F2 Seven Fifty

117 mm / 4,6 in - CB750 Nighthawk

Fuel economy3,7 l / 100 km (60 km/h)
ENGINETypeAir/oil-cooled 4-stroke
Cylinder arrangement4-cylinders in-line
Bore & Stroke67,0 x 53,0 mm
Displacement747 cm³ (45,6 cu in)
Compression ratio9.3:1
Valve trainChain driven DOHC, 4 valves per cylinder (with cam followers)
Max. power75 hp (55 kW) / 8500 rpm
Max. torque64 Nm (6,5 kgm) / 7500 rpm
0 to 100 km/h (0-60 mph)3,9 sec
Top speed205 km/h (127 mph)
CARBURETION SYSTEMTypeCarburetors, 4x Keihin 34 mm
IDVE66X, VE77X – CB750 (1991-2000)

VENAC – CB750 (2001-2008)

DRIVE TRAINClutchWet, multi-plate, cable operated
Transmission5-speed
Final driveChain
Primary reduction1.780
Final reduction2.667 - CB750 F2 Seven Fifty

2.533 - CB750 Nighthawk

Gear ratio

I

II

III

IV

V


3,000

2,056

1,545

1,240

1,074

ELECTRICALIgnitionFull transistor
Alternator
Battery capacity12V-14Ah

Images

Honda CB750 (F2 Seven Fifty, Nighthawk): images, gallery.

Honda CB750 Nighthawk
Honda CB750 Nighthawk
Honda CB750 Nighthawk
Honda CB750 F2 Seven Fifty
Honda CB750 F2 Seven Fifty
Honda CB750 F2 Seven Fifty

Videos

Honda CB750 (F2 Seven Fifty, Nighthawk): video.

Manuals

Honda CB750 (F2 Seven Fifty, Nighthawk): manuals, parts, microfiches.
